Mini Electric Four-Wheel Van Truck ST01 EEC With Air Conditioner Fabric Seats LHD Steering for Post
| Brand: | YUANLU |
| Overall Size: | 3320×1080×1700 |
| Wheelbase (mm): | 2200 |
| Battery Type: | LFP |
| Max speed: | ≥45 |
| Range: | ≥80 |
Mini Van
| Payload Capacity up to 500kg | Cargo Bed Size: 1080/1220mm (Optional) | Multi-function LCD Screen |
| Reinforced Chassis Design Charging / Battery Swap Options | Tier-1 Core 3E Systems | Automotive Grade Quality & Standards |
- It utilizes automotive-grade LFP cells and a highstrength steel casing, delivering high overall structural integrity, excellent heat resistance, and superior thermal stability.
- The vehicle features a stamped monocoque cage body structure. High-strength steel plates are utilized in critical areas, ensuring full compliance with EU safety regulations.
- The cargo bed is available in two widths (1080mm or 1220mm), making it versatile enough to handle a wide range of applications.
- Lifetime Frame Warranty, 3-Year/80,000-km Vehicle Coverage, and a 5-Year/150,000-km Battery Guarantee. Automotive-grade Standard & Assurance.
- Payload Capacity: 500 kg. Designed for efficiency and productivity.
- Engineered with a reinforced chassis and high ground clearance for the perfect balance of toughness and capability.
| Basic Parameter | Pioneer Edition | Knight Edition | Flagship Edition | Battery Swap Edition | |
| Overall Dimensions (mm) | 3320x1080x1700 3495x1200x1700(pro) | 3320x1080x1700 3495x1200x1700(pro) | 3320x1080x1700 3495x1200x1700(pro) | 3320x1080x1700 3495x1200x1700(pro) | |
| Wheelbase(mm) | 2200 | 2200 | 2200 | 2200 | |
| Cargo Bed Internal | 1610x1000x325 | 1610x1000x325 | 1610x1000x325 | 1610x1000x325 | |
| Dimensions (mm) | 1790x1120x325(pro) | 17900) | 1790x1120x325(pro) | 1790x1120x325(pro) | |
| Tire Specification | 145/70 R12 | 145/70 R12 | 145/70 R12 | 145/70 R12 | |
| Min.Ground Clearance (Fully Laden)(mm) | ≥140 | ≥140 | ≥140 | ≥140 | |
| Min.Turning Radius(m) | ≤3.9 | ≤3.9 | ≤3.9 | ≤3.9 | |
| Max.Speed(km/h) | ≥45 | ≥45 | ≥45 | ≥45 | |
| Gross Vehicle Weight (kg) | 490 500(pro) | 500/with A/C520 505/with A/C520(pro) | 500/with A/C 520 505/with A/C525(pro) | 470 485(pro) | |
| Rated Payload (kg) | ≥400 | ≥400 | ≥400 | 400 | |
| Curb Weight (kg) | 965 975(pro) | 975/with A/C1000 980/with A/C1000(pro) | 975/with A/C1000 980/with A/C1000(pro) | 945 960(pro) | |
| Range | ≥80 | ≥80 | ≥80 | ≥40 | |
| Motor & Battery | |||||
| Motor Type | PMSM | PMSM | PMSM | PMSM | |
| Battery Type | LFP | LFP | LFP | LFP | |
| Battery Capacity(kWh) | 5.99 | 5.99 | 5.99 | 2.88 | |
| Battery Thermal Management | Natural Air Cooling | Natural Air Cooling | Natural Air Cooling | Natural Air Cooling | |
| Interior | |||||
| Multi-function Meter (7-inch LCD)Rear | - | ● | ● | ● | |
| View Camera | - | ● | ● | ● | |
| Rear Parking Radar · | ● | ● | ● | ● | |
| Comfort | |||||
| Seat Material | Fabric● | Fabric● | Fabric● | Fabric● | |
| Flat Bench Seat (2-person) | ● | ● | ● | ● | |
| Control Devices | |||||
| Electric Power Steering | ○ | ○ | ● | ● | |
| Vacuum Brake Assist | - | ● | ● | ● | |
| Hill Hold Assist | ● | ● | ● | ● | |
| Single Heater | ● | ○ | ○ | ||
| Manual A/C (Heater & Cooler) | - | ○ | ○ | - | |
| Multimedia | |||||
| Bluetooth(Phone Connection) | ● | ● | ● | ● | |
| USB Port (1、18W) | ● | ● | ● | ● | |
| Speaker(1) | ● | ● | ● | ● | |
| Monitoring Platform T-OX (Remote GPS，Geo-fencing，Anti-theftInterconnectivity） | ○ | ○ | ○ | ○ | |
Note：1、(●Standard，○Optional ，-Not Available ）；2 、Range is measured under specific conditions: fully laden, constant speed of 30 km/h, ambient temperature of 30°C. The company reserves the right to modify specifications without prior notice.
| 2.6m³ Cargo Volume | 1080mm Width | Range of 100km |
| Charging / Battery Swap Options | Tier-1 Core 3E Systems | Automotive Grade Quality |
- It utilizes automotive-grade LFP cells and a high-strength steel casing, delivering high overall structural integrity, excellent heat resistance, and superior thermal stability.
- The vehicle features a stamped monocoque cage body structure. Highstrength steel plates are utilized in critical areas, ensuring full compliance with EU safety regulations.
- Class-Leading 3.9m Turning Radius. Effortless 1.08m Width.
- All-new, self-developed Permanent Magnet Synchronous Motor ,5% higher energy efficiency than comparable models,Energy consumption as low as 8.6 kWh per 100 km,Maximum range up to 100 km.
- Lifetime Frame Warranty, 3-Year/80,000-km Vehicle Coverage, and a 5-Year/150,000-km Battery Guarantee. Automotive-grade Standard & Assurance.
- Amassive 2.6 m³ cargo box. Carry more, work smarter.
- Offering both charging and battery swap options, it can be fully powered in as fast as 3 minutes. NO range anxiety entirely.
| Basic Parameters | Pioneer Edition | Knight Edition | Flagship Edition | Battery Swap Edition |
| Overall Dimensions (mm) | 3330x1080x1745(1.8m³) 3495x1200x1925(2.6m3) | 3330x1080x1745(1.8m3) 3495x1200x1925(2.6m3) | 3330x1080x1745(1.8m³) 3495x1200x1925(2.6m3) | 3330x1080x1745(1.8m³) 3495x1200x1925(2.6m³) |
| Wheelbase(mm) | 2200 | 2200 | 2200 | 2200 |
| Cargo Bed Internal | 1655x1030x1050(1.8m3) | 1655x1030x1050(1.8m3) | 1655x1030x1050(1.8m³) | 1655x1030x1050(1.8m³) 1820x1150x1215(2.6m³) |
| Dimensions (mm) | 1820x1150x1215(2.6m³) | 1820x1150x1215(2.6m3) | 1820x1150x1215(2.6m3) | |
| Tire Specification | 145/70 R12 | 145/70 R12 | 145/70 R12 | 145/70 R12 |
| Min.Ground Clearance (Fully Laden)(mm) | ≥140 | ≥140 | ≥140 | ≥140 |
| Min. Turning Radius(m) | ≤3.9 | ≤3.9 | ≤3.9 | ≤3.9 |
| Max. Speed (km/h) | ≥45 | ≥45 | ≥45 | ≥45 |
| Gross Vehicle Weight(kg) | 550(1.8m3) 565(2.6m3) | 555/with A/C580(1.8m³) 570/with A/C595(2.6m3) | 570(1.8m3) 590(2.6m³) | 530(1.8m3) 545(2.6m³) |
| Rated Payload (kg) | ≥400 | ≥400 | ≥400 | ≥400 |
| Curb Weight(kg) | 1025(1.8m³) 1040(2.6m³) | 1035/with A/C1055(1.8m3) 1045/with A/C1070(2.6m³) | 1045(1.8m3) 1065(2.6m3) | 1005(1.8m3) 1020(2.6m3) |
| Range | ≥80 | ≥80 | ≥80 | ≥40 |
| Motor & Battery | ||||
| Motor Type | PMSM | PMSM | PMSM | PMSM |
| Battery Type | LFP | LFP | LFP | LFP |
| Battery Capacity(kWh) | 5.99 | 5.99 | 5.99 | 2.88 |
| Battery Thermal Management | Natural Air Cooling | Natural Air Cooling | Natural Air Cooling | Natural Air Cooling |
| Interior | ||||
| Multi-function Meter (7-inch LCD)Rear | - | ● | ● | ● |
| View Camera | - | ● | ● | ● |
| Rear Parking Radar | ● | ● | ● | ● |
| Comfort | ||||
| Seat Material | Fabric● | Fabric● | Fabric● | Fabric● |
| Flat Bench Seat(2-person) | ● | ● | ● | ● |
| Control Devices | ||||
| Electric Power Steering | ○ | ○ | ● | ● |
| Vacuum Brake Assist | - | ● | ● | ● |
| Hill Hold Assist | ● | ● | ● | ● |
| Single Heater | ● | ○ | ○ | ● |
| Manual A/C (Heater & Cooler) | - | ○ | ○ | - |
| Multimedia | ||||
| Bluetooth(Phone Connection) | ● | ● | ● | ● |
| USB Port(1、18W) | ● | ● | ● | ● |
| Speaker(1) | ● | ● | ● | ● |
| Monitoring Platform T-OX (RemoteGPS, Geofencing, Antithef,Interconnectivity) | ○ | ○ | ○ | ○ |
Note：1、（●Standard，○Optional，-Not Available）；2、Range is measured under specific conditions: fully laden, constant speed of 30 km/h, ambient temperature of 30°C. The company reserves the right to modify specifications without prior notice.
